BREATHING AIR CONDITIONER CCT
Application
The output temperature of the CCT air conditioner is up to ± 20°C below or above the input temperature.
The CCT breathing air conditioner functions according to the principle of airflow separation. It is intended for heating or cooling breathing air which travels from the breathing air filter to the blasting hood.
Technical data
| Min. operating pressure: | 2.5 bar |
| Max. operating pressure: | 5.0 bar |
| Most effective range: | 4.5 - 5.0 bar |
| Min. airflow with regulator at 2,5 bar: | 165 Nl/min |
| Max. airflow with regulator at 5,0 bar: | 320 Nl/min |
| Min. ambient temperature: | -10°C |
| Max. ambient temperature: | +60°C |
| Max. BAH breathing air supply hose length: | 40 m |
| Noise level at 5.0 bar and maximum air flow: | 90 dB(A) |
